Basic Attributes
- Product Type: Solar-powered wall-mounted lamp, PIR motion sensor wall light, solar wall sconce
- Power Supply: Solar DC power supply (12V), no mains connection required
- Control Modes: Light control (auto-on at dusk / auto-off at dawn), PIR motion sensor (5-10m sensing distance, 270° wide angle), remote control dimming/timing (mid-to-high end models), dual mode (light control + motion sensor)
- Material: Lamp body (die-cast aluminum, corrosion-resistant + PC cover / tempered glass), photovoltaic panel (tempered glass surface + aluminum alloy frame), internal components (flame-retardant ABS plastic)
- Protection Grade: IP65 (mainstream), IP66 (high-end), rainproof, dustproof, lightning-proof, corrosion-resistant
- Operating Temperature: -30℃ ~ 70℃, adaptable to harsh outdoor environments in northern and southern regions
- Installation Method: Wall-mounted / gate post-mounted, with included mounting brackets and screws, no professional installation needed
2) Core Component Attributes
- Solar Panel: Monocrystalline silicon (conversion rate 18%-22%, mainstream choice for higher efficiency) / Polycrystalline silicon (conversion rate 15%-18%, cost-effective); power range 5W-30W (household mainstream: 5W-20W)
- Energy Storage Battery: LiFePO4 battery (mainstream, 12V 4Ah-20Ah, cycle life ≥ 2000 times, high safety and stability) / Lithium battery (18650/32650, 3.7V, 4Ah-15Ah, lightweight design)
- LED Light Source: SMD2835/5050 surface mount diodes or integrated COB; power range 3W-30W (household optimal: 5W-20W); color temperature options: 3000K (warm white, for ambient lighting), 4000K (neutral white, balanced brightness), 6500K (cool white, for security lighting)
- Controller: PWM/MPPT charge management module, with overcharge, over-discharge, short-circuit, and reverse connection protection; built-in light sensor and motion sensor chips for intelligent control
Solar wall-mounted street lamps are compact, wall-installed outdoor lighting systems designed for household and small-scale outdoor use. Powered by solar photovoltaic panels, equipped with LED light sources and lithium/LiFePO4 batteries for energy storage, they operate independently without mains wiring or electricity costs. Featuring intelligent control modes (light control + PIR motion sensor) and IP65/IP66 waterproof rating, they are specifically engineered for wall/gate post mounting, providing efficient lighting and security enhancement for doorways, walls, and perimeters. With easy installation and all-weather durability, they are ideal for energy-saving and low-maintenance outdoor lighting needs.
Performance
Charging & Endurance
- Charging Efficiency: Fully charged within 4-6 hours under standard sunlight (≥50,000 lux); charging efficiency retains 50%-80% on cloudy/overcast days
- Lighting Duration: Constant light mode (full brightness): 6-12 hours (depending on battery capacity); Motion sensor mode: 10-24 hours (high brightness when motion detected, low brightness or off during standby)
- Cloudy Day Endurance: Basic models (small battery): 1-2 days; Mid-range models (medium battery): 3-5 days; High-end models (large battery): 5-7 days
- Low-Temperature Performance: Maintains normal charging and discharging at -30℃, suitable for cold northern climates
2) Lighting Performance
- Brightness Output: 3W ≈ 300lm (suitable for small doorways), 10W ≈ 1000lm (suitable for courtyard walls), 20W ≈ 2000lm (suitable for garage entrances), 30W ≈ 3000lm (suitable for large perimeters)
- Beam Angle: 270° wide-angle illumination, ensuring comprehensive coverage of wall-side areas without blind spots
- Light Source Lifespan: LED lifespan ≥ 50,000 hours (equivalent to 10+ years of daily use); no flicker or glare, eye-friendly
- Motion Sensor Sensitivity: Detects human movement within 5-10m, with adjustable delay time (15-60 seconds) for auto-dimming/off
3) Durability & Reliability
- Structural Durability: Die-cast aluminum shell resists impact and corrosion; PC/tempered glass cover is shatterproof and scratch-resistant
- Wind Resistance: Withstands wind speeds up to 12 levels (due to wall-mounted design and compact structure)
- Long-Term Stability: PV panel power generation attenuation ≤ 10% within 10 years; battery capacity retention ≥ 80% after 3 years of use
Application
Core Household Scenarios
- Gate posts and doorways: Provides targeted lighting for entry areas, enhancing safety when arriving home at night
- Courtyard walls and garden fences: Illuminates walkways and perimeters, preventing tripping hazards and deterring intruders
- Balcony exteriors and terraces: Adds ambient lighting for outdoor leisure areas, no wiring required
- Garage entrances and side doors: Ensures clear visibility for parking and accessing secondary entrances
- Villa and homestay perimeters: Complements landscape design while providing security lighting
2) Extended Application Scenarios
- Rural self-built house doorways (no mains access)
- Small commercial storefronts (energy-saving exterior lighting)
- Community corridors and stairwell exits (auxiliary lighting)
- Construction site temporary perimeters (portable security lighting)
- Farm and fishpond checkpoints (outdoor monitoring supplementary lighting)
Specifications
Mainstream Household Models
2) Physical Specifications
- Dimensions: Lamp body (L×W×H): 15cm-30cm × 10cm-20cm × 8cm-15cm; PV panel size: 20cm×15cm-40cm×30cm (varies by power)
- Weight: Basic model: 0.8kg-1.5kg; Mid-range model: 1.5kg-2.5kg; High-end model: 2.5kg-4kg
- Mounting Requirements: Suitable for walls/gate posts with thickness ≥5cm; mounting height: 1.5m-2.5m (optimal sensing and lighting range)
