Basic Attributes
- Product Type: Outdoor wall-mounted LED solar lamp, solar-powered PIR motion sensor wall light, waterproof solar wall sconce
- Power Supply: 12V DC solar energy supply, off-grid operation (no mains connection required)
- Control Modes: Light control (auto-on at dusk/auto-off at dawn), PIR motion sensor (5-12m sensing distance, 270° wide angle), remote control dimming/timing (mid-to-high-end models), dual mode (light control + motion sensor: high brightness on motion, low brightness standby)
- Material: Lamp body (die-cast aluminum, corrosion-resistant, anti-oxidation); Lamp cover (tempered glass/PC, shatterproof, scratch-resistant); Solar panel (tempered glass surface + aluminum alloy frame); Internal housing (flame-retardant ABS plastic)
- Protection Grade: IP65 (mainstream), IP66/IP67 (high-end), rainproof, dustproof, lightning-proof, corrosion-resistant
- Operating Temperature: -30℃ ~ 70℃, adaptable to extreme weather conditions (hot summers, cold winters)
- Installation Method: Wall-mounted/gate post-mounted, included mounting brackets and stainless steel screws, tool-free quick installation (15-20 minutes per unit)
2) Core Component Attributes
- Solar Panel: Monocrystalline silicon (conversion rate 18%-23%, high efficiency, mainstream); Polycrystalline silicon (conversion rate 15%-18%, cost-effective); Power range: 5W-35W (household/commercial mainstream: 8W-25W)
- Energy Storage Battery: LiFePO4 battery (mainstream, 12V 5Ah-25Ah, cycle life ≥ 2000 times, high safety, low self-discharge); Lithium battery (18650/32650 series, 3.7V, 4Ah-18Ah, lightweight); BMS (Battery Management System) integrated for overcharge/over-discharge/short-circuit/reverse connection protection
- LED Light Source: High-brightness SMD2835/5050/COB; Power range: 5W-30W (household optimal: 8W-20W); Color temperature: 3000K (warm white, ambient lighting), 4000K (neutral white, balanced brightness), 6500K (cool white, security lighting); CRI (Color Rendering Index) ≥ 80 (true color reproduction)
- Controller: PWM/MPPT charge management module (MPPT for high-end models, 10%-15% higher charging efficiency); Built-in light sensor (sensitivity adjustable) and PIR motion sensor chip
Outdoor wall-mounted LED solar street lamps are compact, energy-efficient outdoor lighting solutions designed for wall/gate post installation. Integrating high-efficiency monocrystalline/polycrystalline solar panels, long-life LED light sources, and safe LiFePO4/lithium batteries, they operate independently without mains wiring—charging via sunlight during the day and automatically illuminating at night. Equipped with intelligent control systems (light control + PIR motion sensor) and IP65+ waterproof protection, these lamps combine security lighting, energy savings, and easy installation, making them ideal for residential, commercial, and light industrial outdoor perimeter lighting needs.
Performance
Charging & Endurance
- Charging Efficiency: Fully charged in 4-6 hours under standard sunlight (≥50,000 lux); 50%-85% charging efficiency on cloudy/overcast days; 30%-60% efficiency on rainy days (weak light)
- Lighting Duration:
- Constant light mode: 6-14 hours (full brightness, depending on battery capacity and LED power)
- Motion sensor mode: 12-30 hours (high brightness: 30-60 seconds per motion trigger; low brightness standby: 10%-30% of full power)
- Cloudy Day Endurance: Basic models (small battery): 1-3 days; Mid-range models (medium battery): 3-7 days; High-end models (large battery): 7-12 days
- Low-Temperature Adaptability: Normal charging/discharging at -30℃; Battery capacity retention ≥ 70% at -20℃
2) Lighting Performance
- Brightness Output: 5W ≈ 500lm (small doorways); 10W ≈ 1000lm (courtyard walls); 20W ≈ 2000lm (garage entrances); 30W ≈ 3000lm (large perimeters)
- Beam Angle: 270° wide-angle illumination (no blind spots for wall-side areas); Light distribution uniform, no glare
- LED Lifespan: ≥ 50,000 hours (equivalent to 12+ years of daily use); Low power consumption, energy-saving up to 90% compared to traditional incandescent lamps
- Motion Sensor Performance: Sensing distance 5-12m (adjustable); Response time ≤ 0.5 seconds; Delay time 15-120 seconds (adjustable); Pet-proof function (optional, ignores animals ≤ 20kg)
3) Durability & Reliability
- Structural Durability: Die-cast aluminum shell resists impact (IK08 grade) and corrosion; Tempered glass/PC cover withstands hail and UV radiation
- Weather Resistance: IP65/IP66/IP67 waterproof; Resists strong wind (≥12 levels), heavy rain, and dust
- Long-Term Stability: Solar panel power attenuation ≤ 10% within 10 years; Battery capacity retention ≥ 80% after 3 years; Lamp body color fastness ≥ 4 grades (no fading in sunlight)
Application
Residential Applications
- Villa/garden walls, gate posts, and doorways (entry lighting & security)
- Courtyard fences, balcony exteriors, and terrace perimeters (ambient & safety lighting)
- Garage entrances, side doors, and backyard walls (targeted task lighting)
- Rural self-built houses and homestays (no mains access required)
2) Commercial & Industrial Applications
- Small storefronts, office building entrances, and community corridors (facade lighting)
- Hotel/villa perimeters, resort pathways, and 民宿 walls (atmospheric & security lighting)
- Warehouse loading docks, factory perimeters, and construction site temporary walls (workplace safety lighting)
- Park pavilions, scenic area rest spots, and outdoor public toilets (public facility lighting)
3) Special Scenarios
- Remote areas without mains power (mountain cabins, farms, fishpond checkpoints)
- Historical building exteriors (no wiring damage to structures)
- Temporary event venues (outdoor weddings, pop-up stores)
Specifications
Mainstream Models (Household & Commercial)
2) Physical Specifications
- Dimensions: Lamp body (L×W×H): 18cm-35cm × 12cm-22cm × 8cm-16cm; Solar panel size: 25cm×18cm-45cm×30cm (varies by power)
- Weight: Basic model: 1.0kg-1.8kg; Mid-range model: 1.8kg-3.0kg; High-end model: 3.0kg-5.0kg
- Mounting Requirements: Suitable for concrete/brick/metal walls/gate posts (thickness ≥5cm); Optimal mounting height: 1.8m-2.5m (maximizes sensing and lighting range)
- Additional Accessories: Mounting brackets, stainless steel screws, user manual, remote control (mid-to-high-end models)
